FAKRA SMB-J1.0-1 I Beige



• The product technical characteristics:
   Body:  Brass, Ni-plated
   Socket:  beryllium-copper, Gold-plated
   Pin contact:  Brass
   Insulator: PTFE Crimp ferrule: brass, Ni-plated
   O-ring:  beryllium-copper
   Shell:  PA66+30%GF
• Technical characteristics 50Ω
   Impedance:
   Frequency Range:  4GHz
   Withstanding Voltage:  1000V(RMS)
   Contact resistance: Center contact: ≤ 20m     Outer contact: ≤10m
   Insulation:  ≥1,000MΩ
   VSWR: DC - 2GHz<1.2
• Mechanical characteristics:
   Assembly: locked
   Durability:  ≥ 500 cycles
   Temperature:  - 40 - +85°C

         Car Radio Aerial Antenna Connector Cable FAKRA,Custom FAKRA I Type RF connector,FAKRA
Male Connetor With double Spring,Beige color
              For 0.81 1.13 1.32 1.37 RG178 RG174 RG316 RG58 RTK031 Cable For VW Volkswagen

                FAKRA connector is one of the auto parts. They are widely used in GPS, Remote
control, car phone, car TV, hi-fi equipment, antennas, etc. It is mate with the same colors
or connector and socket, and the structure is to be double-locked and fool-proofing  fo
r them.
          Shenzhen Sihanming technology Co., Ltd. (Shenzhen Sihan Commumication Technology)
was established in 2006. Our company occupies 4500 square meters filed. There are more  than
100 employees, 15% of them are engineers and technicians . We are professional in  designing,
developing,producing and sale of radio frequency coaxial connectors.






































  • *
  • *
