BNC RF coaxial connectors are widely used in communications equipment, instrumentation, video
surveillance, and other fields, enabling low-loss, interference-resistant transmission of RF
signals (such as high-frequency electrical and video signals). Their metal housing provides excellent
electromagnetic shielding, effectively reducing signal crosstalk.

The connector is compatible with SYV-75-2-1, RG-179, and 1.5C-2V cables.

Connector Materials:
Center Pin: Brass plated with gold；
Shell: Brass with Nickel Plating;
Insulator: PTFE;
Copper tube: Brass plated with gold

We offer high-quality, high-volume production. Custom lengths and sizes are also available at reasonable
prices, ensuring safety and reliability.

BNC CONNECTOR

Product Design Level：	Universal connector
Working Voltage：500V r.m.s	500V r.m.s
Temperature Range：	-55℃～＋125℃
Frequency Range：	DC-1GHz
Impedance：	75Ω
Contact Resistance：	Center Contact≤1.5mΩ          Outer Contact≤1mΩ
Insulation Resistance：	≥5000MΩ
Medium Pressure：	1500V
Shell Retention：	≥0.57Ｎ
Environment temperature:	-55℃～+155℃(PE Cable-40℃～+85℃)
