SSMB公头接RG174线

SSMA 是一种小型化的 SMA，界面于 SMA 系列相似，它适合于更小的电缆。SSMA 采用 10-36 UNS 螺纹连接，它的性能类似于 SMA 系列。由于 SSMA 具有比 SMA 更小的尺寸，它适合更小的电缆。它同样具有面板安装、印制电路板(PCB)安装等多种形式，使用它能达到更高密度的安装。产品标准: MIL-C-39012 IEC169-18 CE CC22140 产品特点:10-36 UNS 的英制螺纹使连接器连接可靠，尺寸小，结构牢固。工作频带宽。SSMA 系列产品可以达到 35GHz。比 SMA 系列连接器尺寸更小，安装密度更高。产品性能可靠，机械耐久性好，可以适配多种电缆。

Product Description

SSMA 是一种小型化的 SMA，界面于 SMA 系列相似，它适合于更小的电缆。SSMA 采用 10-36 UNS 螺纹连接，它的性能类似于 SMA 系列。

由于 SSMA 具有比 SMA 更小的尺寸，它适合更小的电缆。它同样具有面板安装、印制电路板(PCB)安装等多种形式，使用它能达到更高密度的安装。

产品标准: MIL-C-39012 IEC169-18 CE CC22140 产品特点:10-36 UNS 的英制螺纹使连接器连接可靠，尺寸小，结构牢固。工作频带宽。SSMA 系列产品可以达到 35GHz。比 SMA 系列连接器尺寸更小，安装密度更高。产品性能可靠，机械耐久性好，可以适配多种电缆。

技术特性:

特性阻抗:50Ω，75Ω

极限频率:6GHz

驻波比:1.1+0.02f(GHz) For RG316/

插入损耗:0.250×√f(GHz)

耐电压:750V / 50 Hz

绝缘电阻: ≥1000MΩ

接触电阻:中心导体间 ≤5 mΩ ;外导体间 ≤1 mΩ

机械参数

插入力 ≤25N

拔出力 8N-20N

接触保持力 ≥10N

插拔次数 ≥500cycles

使用环境

温度范围 -55°C (-67°F)up to +155°C(+311°F)

湿度 MIL-STD-202

振动 MIL-STD-202

耐蚀性 MIL-STD-202

材料

壳体黄铜

中心接触体:插针黄铜 ;插孔铍铜

外接触体铍铜

压接套管铜

其它金属件黄铜

绝缘材料聚四氟乙烯
