This is a high-performance multi-band satellite navigation antenna featuring high gain,
low phase center error, and a wide temperature range. It is suitable for vehicle-mounted,
ship-mounted, and surveying applications where high positioning accuracy is required.

Frequency Bands: 1559-1605MHz/1166-1278MHz, covering multiple frequency bands of GPS, BeiDou,
and other satellite navigation systems.

Polarization: Right-hand circular polarization

Gain: ≥5.5dBi at 90° elevation, ≥0dBi at 20° elevation, ≥-3dBi at 10° elevation

Connector Type: TNC-K (TNC female)

Dimensions: Φ165×68mm

Relative Humidity: 90%, adaptable to high humidity environments.

Operating Temperature: -45~+85℃. Stable operation or storage in extreme temperature ranges.

We offer high-quality, high-volume production. We also offer customized lengths and sizes at
reasonable prices, ensuring safety and reliability. Inquiries are welcome.
